Product description
3 Product description
FRONTAL VIEW
1 Lid with handle
2 Lateral closure (6x)
3 Control panel
4 Locking wheels
REAR VIEW
5 Cover with intake manifold
6 Fine filtration element
7 activated carbon element
8 Lower part (turbine casing)
9 Electronics cover
10 Nameplate
11 Connections
12 Exhaust vents
13 Intake manifold with/without cover
13
