Operation
•
LED flashes red 1x: Blocked rotor
•
LED flashes red 2x: excessive temperature controller
•
LED flashes red 3x: excessive temperature motor 1
•
LED flashes red 4x: low voltage
•
LED flashes red 5x: Excessive temperature motor 2
•
LED flashes red 6x: No turbine detected
•
LED flashes red 7x: 24V voltage power supply too low (below 20V)
FILTER STATUS DISPLAY
Serves as an indicator for the filters and an occurring error:
•
LED Off: Device is voltage-free, in no-load operation or in the event of a device error
•
Green LED, all filters ok
•
Yellow LED: Fine filter 80% full
•
Red LED: Fine filter full
•
LED Red flashing (1sec): Minimum flow rate value not reached
•
LED Blue: Activated carbon full
6.2 Status display overview table
Device status Filter status Signal generator
Atmos staked Off Off Off
Atmos Off / Idle Blue Off Off
Switch Atmos on (press key
>0.5 sec. or autostart)
green green Short beep
Normal operation green green Off
Fine filter > 80% green yellow Off
Fine filter 100% Red Red To
Minimum flow rate not
reached
Red Red flashing (1 sec.) To
Check activated carbon
filter
yellow Blue To
Rotor stuck Red flashes 1x Off To
Overtemperature
electronics
Red flashes 2x Off To
excessive temperature
motor 1
Red flashes 3x Off To
low voltage Red flashes 4x Off To
Excessive temperature
motor 2
Red flashes 5x Off To
No turbine detected Red flashes 6x Off To
21
