TSC Alpha-40L RFID User Manual

76
memory bank
EPC
-
EPC 12 bytes data area
TID
-
Tag identification 8 bytes area (currently not applicable
for RFID WRITE)
USR
-
User 32 bytes area
ACS
-
4 bytes access code area
KIL
-
4 bytes kill code area
PC
-
2 bytes PC code area (Gen 2 tags only)
data
WRITE = content of data string
READ = [prompt of data]
Note:
- RFID WRITE supported "string" or basic variable (e.g. VAR$)
- [ ] = Optional parameter
Sample Code
Example 1
This programming example writes a data into an RFID tag and reads the written data with a prompt.
CLS
RFID WRITE,0,H,0,12,EPC,"123456789012"
RFID READ,0,H,0,12,EPC,"Read Data: "
PRINT 1
