TSC DA200 Series Service Manual

DA200/ DA300
Bar Code Printer Service Manual
23
7. Install back 2 sprints onto the
new printhead module.
8. Pressing both sides of new printhead module let latches into the printer inner
cover. Then lift up them, let latches into the socket.
9. Press down both tabs of
printhead fixing cover into the
printer inner cover.
10. Connect the prinhead harness
and ground cable.
Latch
Press
Press
