TSC MB240 Series Service Manual

III
3.12 Replacing the Gap/Black Mark Sensor Module ....................................................................................................................................... 23
3.13 Cutter Module Installation (Option) ......................................................................................................................................................... 25
3.14 Peel-off Kit Installation (Option) .............................................................................................................................................................. 27
3.15 Slot-in Wireless Housing Installation (Option) ......................................................................................................................................... 31
3.16 GPIO Interface Assembly Installation (Option) ........................................................................................................................................ 32
3.17 Bluetooth Module Installation (Option) .................................................................................................................................................... 35
3.18 Linerless Kit Installation (Option) ............................................................................................................................................................ 36
4. Troubleshooting ......................................................................................................................................................................................... 43
4.1 Common Issues ...................................................................................................................................................................................... 43
4.2 Knob Adjustment .................................................................................................................................................................................... 46
4.2.1 Print head Pressure Adjustment Knob .......................................................................................................................................... 46
4.2.2 Ribbon Tension Adjustment Knob ................................................................................................................................................. 47
4.2.3 Mechanism Fine Adjustment to Avoid Ribbon Wrinkles .............................................................................................................. 48
5. Maintenance ............................................................................................................................................................................................... 51
Revision History ................................................................................................................................................................................................ 54

TSC MB240 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Operating Humidity	25-85% non-condensing
Connectivity	USB 2.0, RS-232
Media Sensor	Reflective, Transmissive
Media Type	Continuous, Die-cut, Black mark, Fan-fold, Notched
Media Width	25.4 mm
Media Thickness	0.06 mm
Media Core Diameter	25.4 mm (1")
Media Max Roll Diameter	127 mm (5")
Ribbon Width	110 mm
Ribbon Length	300 m
Ribbon Core Diameter	25.4 mm (1 inch)
Power	100 - 240 VAC, 50/60 Hz
Maximum Print Length	9999 mm
Label Width	25.4 mm
Label Thickness	0.06 mm
Power Supply	100-240V AC, 50-60Hz
Operating Temperature	5°C - 40°C
Storage Temperature	-20°C - 60°C
Certifications	CE
