TSC TE200 series - Media Specifications

5
1.6 Media Specifications
Media Specifications
TE200
(203 dpi model)
TE300
(300 dpi model)
Label roll capacity 5” OD, 75m
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type Outside wound
Media width 20mm ~ Max. 112 mm
Media thickness 0.06 mm (2.36 mil) ~ 0.19 mm (7.48 mil)
Media core diameter 1” (25.4 mm) & 1.5” (38 mm) ID core
Tear mode 50 mm ~ Max. print length
Note: Media can be torn at the same direction.
Label length 10 mm ~ Max. printing length
Label length (peeler mode) N/A
Label length (cutter mode) N/A
Gap height Min. 2 mm (0.09”)
Black mark height Min. 2 mm (0.09”)
Black mark width Min. 8 mm (0.31”)
