TSC TE200 series User Manual

14
3.3 Loading the Media
3.3.1 Loading the Roll Labels
1. Open the printer top cover by
pressing the top cover open tabs
located on each side of the printer.
2. Insert the paper roll into the media
supply spindle and use two fixing
tabs to fix the paper roll onto the
center of the spindle. (If your paper
width is 4”, you can remove the 1.5”
adapters on both side of the media
supply spindle.)

TSC TE200 series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm
Max Print Speed	6 ips
Memory	8 MB Flash, 8 MB SDRAM
Interface	USB 2.0
Max Print Length	110 inches
Media Type	Labels, Tags, Tickets
Media Width	25.4 mm - 112 mm
Media Core Diameter	25.4 mm (1 inch), 76.2 mm (3 inch)
Label Length	0.39 inches to 110 inches
Ribbon Width	33.8 mm ~ 110 mm (1.33" ~ 4.33")
Ribbon Core Diameter	0.5 inches
Power	100-240V AC, 50-60Hz
Dimensions	204 mm (W) x 164 mm (H) x 280 mm (D)
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Media Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
