TSC TE200 series User Manual

20
Power on utilities The LED color will be changed as following pattern:
LED color
Functions
Amber Red
(5 blinks)
Amber
(5 blinks)
Green
(5 blinks)
Green/Amber
(5 blinks)
Red/Amber
(5 blinks)
Solid green
1. Gap / black mark sensor calibration
Release
2. Gap / black mark sensor calibration,
Self-test and enter dump mode
Release
3. Printer initialization
Release
4. Set black mark sensor as media
sensor and calibrate the black mark
sensor
Release
5. Set gap sensor
as media sensor and
calibrate the gap sensor
Release
6. Skip AUTO.BAS
Release
4.3.1 Gap/Black Mark Sensor Calibration
Gap/black mark sensor sensitivity should be calibrated at the following conditions:
1. A brand new printer
2. Change label stock
3. Printer initialization
Please follow the steps below to calibrate the ribbon and gap/black mark sensor.
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED becomes red and blinking. (Any red will do during the 5 blinks).
 It will calibrate the ribbon sensor and gap/black mark sensor sensitivity.
 The LED color will be changed as following order：
Amber  red (5 blinks)  amber (5 blinks)  green (5 blinks)  green/amber (5 blinks)
 red/amber (5 blinks)  solid green
Note:
Please select gap or black mark sensor by sending GAP or BLINE command to printer prior to
calibrate the sensor.
For more information about GAP and BLINE command, please refer to TSPL/TSPL2 programming
manual.

TSC TE200 series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm
Max Print Speed	6 ips
Memory	8 MB Flash, 8 MB SDRAM
Interface	USB 2.0
Max Print Length	110 inches
Media Type	Labels, Tags, Tickets
Media Width	25.4 mm - 112 mm
Media Core Diameter	25.4 mm (1 inch), 76.2 mm (3 inch)
Label Length	0.39 inches to 110 inches
Ribbon Width	33.8 mm ~ 110 mm (1.33" ~ 4.33")
Ribbon Core Diameter	0.5 inches
Power	100-240V AC, 50-60Hz
Dimensions	204 mm (W) x 164 mm (H) x 280 mm (D)
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Media Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
