TSC TE200 series User Manual

3
Text, bar code, graphics/image printing (Please refer to the
TSPL/TSPL2 programming manual for supporting code
page)
Supported bar code
Supported image
1D bar code
2D bar code
BITMAP,
BMP,
PCX
(Max. 256 colors
graphics)
Code128UCC,
Code128 subsets
A、B、
C, EAN128,
Interleaved 2 of 5,
Interleaved 2 of 5
with check digit,
Code39, Code39
with check digit,
Code93, EAN13,
EAN8, UPCA,
UPCE, EAN and
UPC 2 (5) digits
add-
on, Codabar,
Postnet, MSI, MSI
with check digit,
PLESSEY, China
post, ITF14,
Code11, TELEPEN,
TELEPENN,
PLANET, Code49,
Deutsche Post
Identcode, Deutsche
Post Leitcode,
LOGMARS
GS1 DataBar,
GS1
DataMatrix,
Maxicode,
AZTEC,
PDF417, QR
Code, Micro
PDF 417
○ ○
1.2.2 Printer Optional Features
The printer offers the following optional features.
Product option feature
User
options
Dealer
options
Factory
options
Extended plate for external roll mount assembly with
3” core label spindle (8.4 OD)
○
- -
Internal Bluetooth v4.0 - -
○

TSC TE200 series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm
Max Print Speed	6 ips
Memory	8 MB Flash, 8 MB SDRAM
Interface	USB 2.0
Max Print Length	110 inches
Media Type	Labels, Tags, Tickets
Media Width	25.4 mm - 112 mm
Media Core Diameter	25.4 mm (1 inch), 76.2 mm (3 inch)
Label Length	0.39 inches to 110 inches
Ribbon Width	33.8 mm ~ 110 mm (1.33" ~ 4.33")
Ribbon Core Diameter	0.5 inches
Power	100-240V AC, 50-60Hz
Dimensions	204 mm (W) x 164 mm (H) x 280 mm (D)
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Media Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
