TSC TE200 series User Manual

22
 Self-test
Printer will print the printer configuration after gap/black mark sensor calibration. Self-test
printout can be used to check if there is any dot damage on the heater element, printer
configurations and available memory space.
Self-test printout
Model name
F/W version
Firmware checksum
Printer S/N
TSC configuration file
System date
System time
Printed mileage (meter)
Cutting counter
Print speed (inch/sec)
Print darkness
Label size (inch)
Gap distance (inch)
Gap/black mark sensor intension
Code page
Country code
ZPL setting information
Print darkness
Print speed (inch/sec)
Label size
Control prefix
Format prefix
Delimiter prefix
Printer power up motion
Printer head close motion
Note:
ZPL is emulating for Zebra
®
language.
RS232 serial port
configuration

TSC TE200 series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm
Max Print Speed	6 ips
Memory	8 MB Flash, 8 MB SDRAM
Interface	USB 2.0
Max Print Length	110 inches
Media Type	Labels, Tags, Tickets
Media Width	25.4 mm - 112 mm
Media Core Diameter	25.4 mm (1 inch), 76.2 mm (3 inch)
Label Length	0.39 inches to 110 inches
Ribbon Width	33.8 mm ~ 110 mm (1.33" ~ 4.33")
Ribbon Core Diameter	0.5 inches
Power	100-240V AC, 50-60Hz
Dimensions	204 mm (W) x 164 mm (H) x 280 mm (D)
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Media Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
