TE200/TE210/TE300/TE310 Series

Bar Code Printer Service Manual

4. Please remove the screw

and all of the cables

connected to the main board

and disengage the print

engine.

5. Push the print engine forward and leave the slots, then lift it up to

disconnect the print cover assembly.

6. Reassemble the parts in the

reverse procedure.

Slots

Screw
