TSC TTP-225 Series - 3. Setup; 3.1 Setting Up the Printer; 3.2 Loading the Media; 3.2.1 Loading the Media

TTP-225/323
Bar Code Printer Service Manual
9
Option board
Connector
Description
Remark
1
Ethernet connector/ RJ-45
JP4
2
Main board connector
JP50
2
1
