1
TTP-225/TTP-323
Bar Code Printer Service Manual
1. OVERVIEW
1.1 Front View
1. LCD display (Factory option)
2. LED indicator
3. Feed button
4. Paper exit chute
5. Media view window
6. Top cover open lever
2
6
5
4
1
