TSC TTP-225 Series Service Manual

2
TTP-225/TTP-323
Bar Code Printer Service Manual
1.2 Interior View
1. Ribbon access cover
2. Ribbon rewind hub
3. Ribbon rewind gear
4. Print head
5. Ribbon supply hub
6. Gap sensor (receiver)
7. Media holders
8. Media guide
9. Top cover support
10. Black mark sensor
11. Platen roller
12. Gap sensor (transmitter)
13. Media guide adjuster knob
14. Top cover
4
11
6
8
10
7
1
12
5
2
3
9
13
14
