TSC TTP-225 Series Service Manual

TTP-225/323
Bar Code Printer Service Manual
15
5. Disconnect all connectors from the main board.
6. Remove/Replace the main board and RS-232/Ethernet interface board.
7. Take off the interface plate from the lower cover.
8. Reassemble the PCB, lower cover and lower front cover in reverse procedures.
Main board
RS-232
Interface
board
Interface plate
Ethernet
Interface
board
(Option)
Screws
