18
3.3 Replacing the Power Supply Unit
1. Refer to section 3.1 to remove the electronics cover.
2. Disconnect 2 connectors, and remove 2 screws on the power supply unit.
3. Replace the power supply unit.
4. Reassemble the parts in the reverse procedures.
Screws
