TSC TTP-368MT Series - Slot-In Wifi Housing Installation (Option)

40
3.14 Slot-in Wifi Housing Installation (Option)
1. Fix the WiFi module with machine screw M3*6/ button head screws. Tightening
torque: 5KG
2. Insert the housing board cable to the main board.
3. Please make sure the LCD flat cable (white) is fixed on front of printer by a label.
Pull the cable to left
