19
3.4 Replacing Multi-interface Board
1. Refer to section 3.1 to remove the electronics cover.
2. Remove 2 screws from multi-interface board. Disconnect 2 connectors.
3. Replace the multi-interface board.
4. Reassemble the parts in the reverse procedures.
Screws
