TSC TTP-368MT Series - Peel-Off Kit Installation

30
3.13 Peel-off kit Installation
Peel-off kit parts list
1. Internal rewinder spindle
2. Harness for DC motor control board
3. Peel-off cover (Including peel-off sensor assembly)
4. Screw # 1
5. Gear
6. Pillar
7. Screw # 2
8. Copper pillar
9. Screw # 3
10. DC motor control board assembly
11. DC motor kit (Including DC motor and sensor assembly)
12. Screw # 4
13. Platen holder
1
2
3
4
5
6
7
8
9
10
11
12
13
