TSC TTP-368MT Series - Page 39

38
22. Connect the DC motor harness and the DC motor control board harness to main
board. Then, reassemble the parts in the reverse procedures.
23. Loosen 4 screws to remove lower front panel and platen holder.
24. Use 2 screws to install the new platen holder (No.13) as indicated.
