TSI Instruments SIZER 3321 - Pin Connectors; SERIAL PORT Pin Designations

C-1
A P P E N D I X C
Using Serial Data
Commands
This chapter contains information you need if you are writing your own
software for a computer or data acquisition system. Information includes:
 Pin connectors
 Baud rate
 Parity
 Command definitions and syntax.
 Examples, as well as input and troubleshooting directions are also
provided.
Pin Co n n e ctors
The Model 3321 has a single 9-pin, D-subminiature connector port on the
back panel labeled SERIAL PORT (See Figure 3-3 and Figure C-1). This
communication port is configured at the factory to work with RS-232 type
devices. Table C-1 provides the signal connections.
5 4 3 2 1
9 8 7 6
Figure C-1
SERIAL PORT Pin Designations
