SMA—Set Mode for Analog Output
SMA sets the mode and range for the analog output BNC on the back
panel
SMAx
where:
x = 0 to 6
0 = total concentration 1/cc 10 volts.
1 = total concentration 10/cc 10 volts.
2 = total concentration 100/cc 10 volts.
3 = total concentration 1,000/cc 10 volts.
4 = total concentration 10,000/cc 10 volts.
5 = total concentration Log 10,000/cc 5 volts.
1,000/cc 4 volts
100/cc 3 volts
10/cc 2 volts
1/cc 1 volts
.1/cc 0 volts
6 = host.
Table C-3
Analog Voltage Output Settings
SMA
Setting
BNC Analog Output Voltage (V)
X
0
1
2
3
4
5
10
0
0
.1/cc
.2/cc
.3/cc
.4/cc
.5/cc
1/cc
1
0
1/cc
2/cc
3/cc
4/cc
5/cc
10/cc
2
0
10/cc
20/cc
30/cc
40/cc
50/cc
100/cc
3
0
100/cc
200/cc
300/cc
400/cc
500/cc
1000/cc
4
0
1000/cc
2000/cc
3000/cc
4000/cc
5000/cc
10,000/cc
5
.1/cc
1/cc
10/cc
100/cc
1000/cc
10,000/cc
NA
6
0
1v
2v
3v
4v
5v
10v
Examples:
To set the analog output BNC voltage range 0–10 volts, to represent the
total concentration range 0–10,000 particles/cc.
SMA4
To set the analog output BNC to host mode. (See the SV command for the
actual voltage output.)
SMA6
