C-4 Model 3321 Aerodynamic Particle Sizer
®
Spectrometer
Set Commands
SB
SCA
SCL
SCE
SCR
SD
SF
SH
SL
SMA
SMC
SMT
SP
STU
SV
Set Baud rate
SBx
Set Calibration for Aerodynamic diameters
SCAc,s
c
,t
c
Set Calibration Label string
Set Calibration Environment
SCEp,t
Set Calibration Resolution
SCRx
Set Digital output
SDx
Set Front panel enable
SFx
Set Hi Conc threshold
SHx
Set Laser power
SLx
Set Mode for Analog output
SMAx
Set Mode for automatic Calibration of APD
SMCx
Set Mode and sample Time
SMTa,t
Set Pumps
SPx
Set Time for Unpolled report
STUx
Set analog output Voltage
SVx
Action Commands
A
B
C
D
F
G
H
L
Q
S
Autocal the APD
Beep
Bx
Clear buffers and sample time
Dump command
Fill command
Fx
Go (sample)
Gx
Halt command
Laser on/off
Quick concentration report
Sampling
Sx
Read (Polled) Commands
R
RF
RI
RL
RO
RPI
RPS
RPT
RQA
RQS
RQT
RR
RTB
RTD
RTI
RV
Read accumulator
Rb,e
Read status Flags
Read Input from pins 1, 2, 3 and 7, 8 of the
I/O connector
Read Laser power
Read accumulated On time of instrument
Read inlet pressure
Read sheath delta P
Read total delta P
Read aerosol flow
Read sheath flow
Read total flow
Read Unpolled Record
Read Temperature in Box
Read Temperature of APD Detector
Read Temperature of Inlet
Read Version of firmware
Unpolled Commands
U
U+
U-
UA
UB
UC
UD
US
UY
Unpolled operation begins
Enable all records
Disable all records
Accumulator record
UA0/1
SS accumulator record
UB0/1
Correlated (paired) records
UC0/1
Aerodynamic data record
UD0/1
SS data record
US0/1
Auxiliary data record
UY0/1
Figure C-2
Serial Command Tables
