Using Serial Data Commands C-19
RR—Read Record
Reads records A, B, C, D, S or Y. See description of records in following
subsection.
RRx
where:
x = A, B, C, D, S, or Y records
Note: To read C record, you must be in correlated mode (see SMT
command).
Example Response
RRA Record A is returned.
RTB—Read Temperature in Box
Reads the internal temperature of the Model 3321.
Example Response
RTB 298.2
Indicates the internal temperature is 298.2 K or 25.0° C.
RTD—Read Temperature of Detector (APD)
Reads the APD and optics temperature of the Model 3321.
Example Response
RTD 306.6
Indicates the APD and optics temperature is 306.6 K or 33.4° C.
RTI—Read Temperature of Inlet
Reads the inlet temperature constant of the Model 3321. This constant is
used for flow control only and is fixed.
Example Response
RTI 294.7
Indicates the inlet temperature is 294.7 K or 21.5°C.
