TurboChef Eco Service Manual

Figure # Item Description Item Part Number Fastener Description
Fastener Part
Number(s)
1 Clamp, Capacitor
NGC-1439 (60 Hz Ovens)
TC3-0407 (50 Hz Ovens)
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
2
Cooling Fan, Electrical
Compartment
100087 (x3)
SCREW, HEX HD, #10-32 x 1/2 LG, CRES, TYPE 23
GUARD, FINGER, FAN, (120 MM)
101408 (qty 4 per)
100087 (qty 1 per)
3
Cooling Fan, HV Trans-
former
105259 SCREW, #10-32 X 1”, HWHD, TYPE “F”, PLTD STEEL 105268 (qty 3)
4 Cooling Fan, Magnetron 105259 SCREW, #10-32 X 1”, HWHD, TYPE “F”, PLTD STEEL 105268 (qty 3)
5 EMI Filter 100548 NUT #6-32 KEPS EXTERNAL TOOTH SS 102961 (qty 2)
6 HV Capacitor
100214 (60 Hz Ovens)
100217 (50 Hz Ovens)
SCREW, 6-32 X 3/8 PAN PHIL M/S 18-8 SEMS INT LW
NUT #6-32 KEPS EXTERNAL TOOTH SS
102911
102961
7 HV Diode 100481 SCREW #8 x 1/2 101689 (qty 2)
8
HV/Filament Trans-
former
ECO-3204-1 (60 Hz Ovens)
ECO-3204-2 (Japan Ovens)
ECO-3204-3 (50 Hz Ovens)
SCREW, 8-32 X 3/4, PPHD, ZINC
SPACER, #10 (.192) X 3/8 OD X 7/16, AL
104178 (qty 4)
104111 (qty 4)
9 Magnetron NGC-3015 SCREW, SEMS, #8-32 X 5/8 LG, PPHD, CRES 102926 (qty 4)
10 Power Supply NGC-3069 Included in kit Included in kit
11 Relay, K1 (Stirrer Motor) 101275
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
12 Relay, K2 (Anode) 101273
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
13 Relay, K3 (Monitor) 101273
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
14
Relay, K6 (Voltage
Select)
101275
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
15
Relay, K7 (Magnetron
Cooling Fan)
101275
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
16
Solid State Relay
(Heaters)
101286
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
17 Speaker Kit CON-7038
Screw, #8 X 1/2 Phillips, Truss, Type 17, Serrated, 410
SS
101688 (qty 2)
18 Stirrer Coupling Hub 104132 Set Screw (Provided) None
19 Stirrer Motor 105108
SCREW, 6-32 X 3/8 PAN PHIL M/S 18-8 SEMS INT
LW
102911 (qty 2)
20 Stirrer Shaft i1-3214 Included with kit Included
21 Thermostat, Cooling Fan 102086 SCREW, #6 X 3/8, PPH, DRILL POINT, ZINC 101684 (qty 2)
22
Thermostat, HV Trans-
former
104167 SCREW, #6 X 3/8, PPH, DRILL POINT, ZINC 101684 (qty 2)
23 Thermostat, Magnetron 104228 SCREW, #6 X 3/8, PPH, DRILL POINT, ZINC 101684 (qty 2)
24 Waveguide Cover i1-9701 None None
25 Waveguide Gasket i1-9331 NUT, #10-32, HEX, ZINC, SERRATED FLANGE 100913 (qty 9)
26
Waveguide, Eco,
Insulated
ECO-9151 None None
27 Waveguide Seal i1-9486 None None
APPENDIX - OVEN COMPONENTS
A-9

TurboChef Eco Specifications

General

Brand	TurboChef
Model	Eco
Exterior Finish	Stainless Steel
Voltage	208-240V
Frequency	60 Hz
Power Source	Electric
Category	Oven
Phase	1-Phase
Plug	NEMA 6-
Cooking Modes	Convection
Warranty	1 year
TurboChef Technology	Air impingement, microwave
