Rear wheel stand
Use the rear wheel stand (the rear wheel stand is
an accessory and it is available with the TVS Motor
Company Authorised Main Dealer).
• Ensure that the motorcycle is parked on a flat and
firm surface.
• Loosen the clamping screws (1) of the stand
adopters.
• Move away the adopters (2 & 3) in such way that
the swing arm fits between them (ref. Fig. 83).
• Ensure that the axle is not covered.
• Position the stand (ref. Fig. 84).
• Make sure that the vehicle is secured so that it
cannot topple sideways.
• Push the stand down until the motorcycle is
standing upright and the handle of auxiliary stand
is resting on the floor properly.
When raising the motorcycle, make sure that the vehicle
is secured so that it cannot topple sideways.
1
2
3
1
Fig. 83
Fig. 84
