Battery
Ensure the safety precautions listed in the page
127 are followed properly.
Since the maintenance free battery is used in
your motorcycle, it is not necessary to check the
battery electrolyte level or add distilled water.
If your battery seems weak ie. if you are facing
starting issues or other electrical issues, contact TVS
Motor Company Authorised Main Dealer.
Removal
• Turn OFF the ignition.
• Remove the pillion and rider seats as explained in
page no. 99 to access battery.
• Remove the mounting bolt and take the battery
holder (A) (ref. Fig. 69)
• Disconnect the negative terminal (1) first followed
by the positive terminal (2) (ref. Fig. 70). Carefully
take out the battery.
A
2
1
Re-fitment
• Reinstall the battery in the reverse order of
removal.
• Connect the positive terminal first and then the
negative firmly to avoid any damages to electrical
system / battery. Make sure the rubber boot is
intact with positive terminal.
Fig. 69
Fig. 70
