160
Tool Kit
To assist you in performing certain aspects of
periodic maintenance and emergency repairs, a tool
kit is supplied along with the vehicle.
• The tool kit (A, ref. Fig. 78) is located below the
pillion seat (ref. page 99 for seat removal
procedure).
• The tool kit consists of one number each of the
following:
1. Tool bag
2. Double ended open jaw spanner 12x13
3. Double ended open jaw spanner 10x16
It is recommended to use the tool kit incase of any
emergency only. It is always advisable to take your
vehicle to TVS Motor Company Authorised Main Dealer.
4. Bit +/-
5. Grip driver
6. Adjuster shock absorber rear
7. Handle ring spanner
8. Hexagonal key 5 mm
9. Ring spanner
GENERAL INFORMATION
Fig. 78
