TVS Apache RR 310 - Major Components (ref. Fig. 22)

92
Major Components (ref. Fig. 22)
1) Rear view mirrors (ref. page 111)
2) Cooling system (radiator) (ref. page 93)
3) Fuel tank cap (ref. page 95)
4) Seat lock (ref. page 99)
5) Adjustable rear suspension (ref. page 98)
6) Adjustable front suspension (ref. page 98)
7) Coolant reservoir (ref. page 93)
2
1
This section shows the position and operation of the
major components of your motorcycle.
Note
3
4
5
7
* Hidden items are marked with dotted lines
6
Fig. 22
