22
Switch Assembly LH
Switch assembly LH is located in the handle bar at LH
side and has the following switches in it.
A) Switch beam control (ref. Fig. 09)
Head lamp glows automatically when the ignition
turned ON. Depending on the selection of High/
Low beam switch position, head lamp will operate in
corresponding beam.
• Press the switch towards you ‘ ’ to illuminate
low beam
• Press the switch away from you ‘ ’ to
illuminate high beam.
- When the head lamp is illuminated in high
beam, the high beam indicator ‘ ’ glows along
with it.
Use appropriate head lamp beam ‘high / low’ as per
the traffic and road conditions for your safety and avoid
inconvenience to other riders.
A
Fig. 09
