2) TFT Multifunction display (ref. Fig. 21)
A) Menu indication
B) Clock
C) Cooling fan status
D) Bluetooth connectivity indication
E) Mobile signal strength
F) Mobile battery status
A
B DC E
F
Fig. 21
