During time of delivery of the motorcycle, the rear shock
absorber is adjusted to the standard configuration.
Note
- If any leak is found contact TVS Motor Company
Authorised Main Dealer.
Seat Lock (Rider and Pillion Seat)
This motorcycle is equipped with a lockable rider and
pillion seats. The seat lock (A) is located between the
rider and pillion seat as shown (ref. Fig. 31)
To open pillion seat:
• Insert the control key into the seat lock. Rotate
the key in clockwise until the lock is released.
• first, slide the seat towards vehicle front direction.
• Ensure the hook underneath got released from
frame and take out the seat.
A
Fig. 31
