182
Type Three phase AC generator
Ignition system Dynamically controlled - high energy integrated ignition
system
Spark plug NGK (LMAR9D - J)
Spark plug gap 0.8 ± 0.1 mm
Battery type 12V / 8 Ah MF wet charge type
Body earthing Two grounds are mounted on engine body (1. Engine ground
and 2. Ignition ground) and one ground mounted on fuel tank
Generator 12V, 290W
Head lamp 12V, LED
Position lamp 12V, LED
Tail / brake lamp 12V, LED (2W / 2W approx.)
Turn signal lamp 12V, LED (2W each)
Number plate lamp 12V LED
Instrument panel TFT / LED indicators
Horn type 12V DC two numbers
Fuse Mini fuse - 7.5A x 2, 10A x 3, 25A x 1 and 30A x 1
Voltage regulator Three phase shunt full DC RR unit
Electricals
