e1. Speedometer
• Displays the road speed in km/h (f1) (in India) .
e2. Engine rpm indicator
• Digital band (f2) indicates the engine rpm in
multiples of 250 rpm.
• Digital bands are indicated in blue and red band
based on the engine coolant temperature. Refer
bellow table for details.
f1
Engine
Coolant
temperature
Blue band
RPM range
Red band RPM
range
-25°C to 20°C 0 - 5000 rpm 5000 - 12000 rpm
20°C to 60°C 0 - 7000 rpm 7000 - 12000 rpm
60°C to 120°C 0 - 10500 rpm 10500 - 12000 rpm
Above 120°C Engine will cut-off.
f2
