KNOW YOUR APACHE RTR 180
-13-
Caution
Leaving the ignition cum steering lock in ‘ON’
position will drain the battery when vehicle is not in
use . So “Switch off” and take the key out when the
vehicle is unused.
Warning
Never attempt to move the vehicle when the steering
is locked, you may lose balance.
DIGITAL SPEEDOMETER
1. High beam indicator lamp ( )
Glows when the head lamp high beam is activated.
2. Neutral indicator lamp (N)
Glows when the vehicle is in neutral and goes
‘OFF’ if the gear is shifted from neutral.
3. Turn signal indicator lamp ( )
Flashes when the ‘left’ or ‘right’ side turn signal
indication is activated.
4. Digital clock
Displays the time in 12 or 24 hour time format.
Note
If the battery is disconnected and reconnected
during service, the clock displays 12:00 by default.
You need to reset the time (refer page no. 16).
KNOW YOUR APACHE RTR 180
5. Fuel gauge
Fuel gauge indicates the approximate quantity of
fuel available in the fuel tank.
6. Speedometer
Indicates the vehicle speed in kilometers per hour.
10
11
12
6
7 8
9
5
4
3 1
2
