Turn signal lamp : 12V, 10W x 4
Number plate lamp : 12V, 4W x 1
Instrument panel : LCD / LED indicators
Horn : 12V DC x 2
Fuse : 12V 10A x 1
CAPACITIES
Fuel tank capacity : 16.0 litres (including reserve)**
Reserve : 2.5 litres
Engine cum transmission : TVS TRU4 PREMIUM, 4T oil
oil grade
Engine cum transmission : 1000 ml (after draining)
oil and capacity 1100 ml (after disassembly)
Front fork oil grade : IOC teleshockab oil
Front fork oil capacity : 140 ± 2 ml per leg (Gabriel make)
: 152 ± 2 ml per leg (Top make)
Brake fluid : TVS Girling DOT 3 / DOT 4
** The fuel tank is not a measuring instrument and the
capacity of fuel tank may slightly vary from the indicated
capacity.
TECHNICAL SPECIFICATIONS
-54-
Caution
Using the bulb other than the specified rating can
result in overloading of the electrical system or
premature failure of the bulb.
Note
Specifications are subject to change without notice.
TECHNICAL SPECIFICATIONS
