KNOW YOUR APACHE RTR 180
-18-
2. Head lamp switch
Head lamp switch has three positions. working of
head lamp at various positions are as follows:
OFF: All the lamps are turned ‘OFF’ except
position lamp when the switch is positioned
at ‘ ’ even though the engine is running.
PO : Speedometer back illumination, tail lamp
and number plate lamp glows when the
switch is positioned at ‘ ’ and engine is
running.
ON: Head lamp also glows along with the above
said lamps when the switch is positioned at
‘ ‘ and engine is running.
3. Throttle grip
Engine speed is controlled by the rotation of the
throttle grip. Twist it towards you to increase the
engine speed and away from you or release it to
decrease the engine speed.
4. Front brake lever
The front brake is applied by squeezing the front
brake lever gently towards the throttle grip. The
brake lamp glows on application of front brake.
5. Engine cut off switch
To switch off the engine but to keep the battery
activated, press the switch to ‘ ‘ position.
To start the engine, press the switch to ‘ ‘
position.
KNOW YOUR APACHE RTR 180
Note
Before starting, ensure to turn ‘ON’ the engine cut off
switch.
Apache RTR 180 is provided with adjustable LH and
RH handle bar. Contact your TVS Motor Company
Authorised Distributor / Dealer or Authorised Service
Centers for any such adjustment.
Warning
Please do not adjust the handle bar your self or by
any unauthorised persons. Improper adjustment
may affect the maneuverability of the vehicle.
