TVS Apache RTR 180 Hyper Edge User Manual

CHASSIS
Overall length : 2085 mm
Overall width : 730 mm
Overall height : 1105 mm
Seat height : 790 mm
Ground clearance : 165 mm
Wheel base : 1326 mm
Kerb weight (with toolkit : 137 kg
and 90% of fuel)
Pay load : 130 kg
Maximum laden weight : 267 kg
Steering angle : 36°
Caster angle : 25.5°
Frame : D oub le c rad le S ync hro
STIFF
Front suspension : Telescopic oil damped
Rear suspension : Monotube inverted gas filled
5 step adjustable shocks
with rectangular swing arm.
Trail length : 84.3 mm
Turning radius : 2400 mm
TYRE
Tyre size
Front : 90/90 x 17 (Tubeless)
Rear : 110/80 x 17 (Tubeless)
Tyre pressure
2
Front : 1.75 kg/cm (25 PSI)
2
Rear - solo : 2.00 kg/cm (28 PSI)
2
Rear - dual : 2.25 kg/cm (32 PSI)
BRAKES
Front : Hand operated, 270 mm petal
disc
Rear : Foot operated, 200 mm petal
disc
ELECTRICAL
Type : AC generator
Ignition system : IDI - Dual mode digital ignition
Spark plug : B O S C H U R 5 D D C - T W I N
ELECTRODE
Battery type : 12V, 9.0 Ah
Generator : Fly wheel magneto, 12V, 100W
Head lamp : Halogen HS 12V, 35/35W x 1
Position lamp : LED 12V, 3W
Tail / brake lamp : LED indicators (0.5W / 3.5W)
TECHNICAL SPECIFICATIONS
-53-
TECHNICAL SPECIFICATIONS
