5. The oil level should be between the minimum
and maximum level marks of the gauge as
shown in the figure.
6. If the oil level is less than the minimum level,
add ‘TVS TRU4 PREMIUM’ 4T oil upto the
maximum level mark.
7. Wipe out the oil traces with a clean cloth to
prevent dust accumulation and assemble back
the gauge oil level.
ENGINE CUM TRANSMISSION OIL
LEVEL
Check the engine cum transmission oil level
periodically.
1. Place the vehicle on centre stand on a flat
surface. Wipe-off the surroundings of gauge oil
level.
2. Remove the gauge oil level and wipe it clean.
3. Fix the gauge back to its mounting hole and
thread in.
4. Once again remove the gauge and check the oil
level.
MAINTENANCE
MAINTENANCE
-38-
Maximum
Minimum
Caution
If the vehicle is driven with less engine cum
transmission oil, engine components will be severely
damaged. Check the oil level as per the schedule to
avoid costly damage. Do not fill excess oil may cause
oil leak. Always use ‘TVS TRU4 PREMIUM’ 4T oil only.
CLUTCH ADJUSTMENT
Clutch lever free play is one of the most important
adjustment which you may need to check
in-between services for better life of the clutch
plates.
