9. Tachometer
Tachometer indicates the engine speed in
multiples of 1000 rpm (revolutions per minute).
10. Fuel warning indicator ( )
Fuel warning lamp glows continuously for a few
km if the fuel in tank comes to minimum safe level.
This gives warning to the rider that the vehicle is
running with less fuel and it needs to be filled
immediately.
11. Service reminder
If the service is due, whenever the ignition switch
is turned ‘ON’, an icon with spanner symbol
‘ ’ blinks for 10 seconds after the self test cycle
of speedometer, and continues to glow till the
vehicle is serviced and reset. Get the vehicle
serviced at TVS Motor Company Authorised
Distributor / Dealer or Authorised Service Centers.
12. Low battery indicator
An icon with battery symbol ‘ ’ glows when the
battery charge is too low. Get the battery checked
at TVS Motor Company Authorised Distributor /
Dealer or Authorised Service Centers.
KNOW YOUR APACHE RTR 180
-15-
Note
Service reminder indicator lamp works only based on
the distance (km) covered by the vehicle. This is only
a reminder indicator. Customers are advised to keep
track and follow the service schedule.
KNOW YOUR APACHE RTR 180
ODOMETER / TRIP METER / HIGH
SPEED / SHORTEST TIME INDICATOR
SETTING
To change the mode between ‘ODO’, ‘TRIP A’,
‘TRIP B’, ‘HI Spd’ and ‘St’ just press the mode
switch button ‘A’.
A
B
