Adjust the spring pre-load by shifting the adjuster to
the required notch according to the different load
conditions. The more you compress the spring, the
suspension becomes more stiff.
MAINTENANCE
MAINTENANCE
-40-
REAR SHOCK ABSORBERS
Apache RTR 180 is provided with triple rated,
5 step adjustable, monotube inverted gas filled rear
shock absorbers to meet different road and load.
There are 5 notches for adjusting spring load.
If the spring is adjusted to the minimum notch,
then the shock absorber will be softer which is
good for light loads.
If the spring is adjusted to maximum notch, then it
will be stiffer which is good for heavy loads.
SOFT
HARD
Warning
Do not heat / tamper the canister filled with GAS.
Caution
Keep both left and right shock absorbers spring
adjusters in the same position.
