DESCRIPTION OF OPERATION SYSTEM
(1) Diesel Engine
(2) Dosing Module with Injector
(3) Temperature sensor
(4) SCR Catalyst
(5) Temperature sensor
(6) Filter
(7) AdBlue Supply module
(8) AdBlue tank
(9) AdBlue Temperature sensor
(10) Ad Blue level sensor
(11) Dosing control unit
(12) Actuators
(13) Sensors
(14) Engine CAN
(15) Diagnostic CAN
J10O211A
Note) SCR; Selective Catalytic Reduction
