2 -
DESCRIPTION OF OPERATION SYSTEM
< 4WD >
The 4WD function can be operated
in any gear during driving (forward/
reverse driving).
Automatic mode
The 4WD function is automati
-
cally deactivated when the angle
of one of the front wheels is over
20 degrees or the vehicle speed
exceeds 15 km/h.
Pressing the button once turns
on the lamp and activates the
automatic mode. Pressing it
once again turns off the lamp
and deactivates the automatic
mode.
Manual mode
It is possible to control the 4WD
function manually by a driver for
easier operation.
Automatic 4WD Manual 4WD
< SP model >
Examples of useful conditions of
differential lock
One wheel slips or tractor can
-
not be driven forward when mov-
ing into/out of a eld.
A wheel slips during work requir
-
ing traction, such as plowing.
One wheel is stuck into a soft
eld and can't escape.
4WD SHIFT BUTTON
ON - The 4WD function is acti-
vated when pressing the
upper portion of the shift
button.
OFF - The 4WD function is deac-
tivated when pressing the
lower portion of the shift
button.
J10O530A
4WD shift button
< SC model >
Pressing the button once turns
on the lamp and activates the
manual mode. Pressing it once
again turns off the lamp and de-
activates the manual mode.
The differential lock is disengaged
when depressing the brake pedal.
The differential lock is disengaged
when the vehicle speed exceeds
15 km/h.
NOTE
