TYM T1054 - Adjusting Tread

5 - 0
MAINTENANCE
9. ADJUSTING TREAD
ADJUSTING FRONT WHEEL
TREAD
Th e t r ead can be adjust e d b y
switching the rims and discs on the
left and right sides.
AD J U S T I N G R E A R W H E E L
TREAD
Th e t r ead can be adjust e d b y
switching the rims and discs on the
left and right sides.
►
►
For safety, have tread adjustment
performed by your dealer or work-
shop.
Never remove tires if there is no
safe supporting device. The trac-
tor can roll over.
•
•
WARNING
Possible combination of rear wheel
with front wheel table
Rear Wheel Front Wheel
A A
B A B C
C A B C D
D B C D E F G
E D E F G
F F G
