Moving direction Backward
Finish
A: Border
A
Start
(9) (13) (17)
(19) (15) (11)
(18)
(8)
(12)
(16)
(1)
(7)
(2)
(6)
(3)
(5)
(4)
(14)
(10)
995E002A
⊙
Turning:
(2) Alternating returning plowing
pattern
This pattern is useful for narrow
or short elds or poorly planned
fields in which are not easy to
turn.
In the figure, the plowing width
for (1), (2), (3) and (4) should be
overlapped with the one for (5),
(6) and (7) for approx. 10 cm.
For the sections (1) to (7), per-
form plowing in an alternating
pattern. For the sections (8) to
(19), plow in a circular pattern.
Refer to the sequential returning
pattern for other details.
•
•
•
•
