J10O310A
993C011A
J10O311A
(1) Tachometer
It indicates the engine RPM (Ro-
tation Per Minute), The green ar-
row indicates the engine speed
at the standard 540 RPM speed
of the PTO.
(2) Hourmeter
It indicates the total time of use.
Black digits - Whole number for
hours of use
Red digit - Decimal place for
hours of use
There are 6 digits for the hour
meter. The last digit indicates
one tenth hours.
Example) The time of use illus-
trated above is 234 hours and 30
minutes.
•
•
(3) Speedometer
It indicates the driving speed (km/
h) of the tractor.
Tachometer
Speedometer
The engine can be damaged if in-
creasing its speed too fast
.
•
NOTE
