TYM T1054 - LED Blinking by Error Code

5 - 
MAINTENANCE
LED BLINKING BY ERROR CODE
If there is an error in the system, the status LED indicates this error by blinking in the specied setting.
●
: ON
○
: OF
F
►
Faults
code
1phase 2 phase 3 Phase 4 Phase
○
: Pause
●
: Flash
Description
2 sec. First digit 1 sec. Second digit
11
○ ● ○ ●
Indicates Circuit Fault of the Lift Arm solenoid for Raising
12
○ ● ○ ●●
Indicates Circuit Fault of the Lift Arm solenoid for Lowering
13
○ ● ○ ●●●
Indicates Short Fault of the Lift Solenoid for Raising/Lowerring
14
○ ● ○ ●●●●
Indicates Connecting Fault of the Exterior (Raise and Lower) control button for Raising
15
○ ● ○ ●●●●●
Indicates Connecting fFault of the Exterior (Raise and Lower) control button for
Lowering
16
○ ● ○ ●●●●●●
Indicates power Supply Fault of the Lift Arm controller (In short Circuit to +10V)
17
○ ● ○ ●●●●●●●
Indicates power Supply Fault of the Lift Arm controller (In short Circuit to +10V)
22
○ ●● ○ ●●
Indicates Position Sensor Fault
23
○ ●● ○ ●●●
Indicates Setpoint knob fault
24
○ ●● ○ ●●●●
Indicates Upper limit knob fault
28
○ ●● ○ ●●●●●●●●
Indicates Control Lever(Lift / stop / lowering) Switch fault
31
○ ●●● ○ ●
Indicates Left Draft Sensor Fault
32
○ ●●● ○ ●●
Indicates Left Draft Sensor Fault
33
○ ●●● ○ ●●●
Indicates Low battery voltage fault (below+8v)
34
○ ●●● ○ ●●●●
Indicates Lowering speed control knob fault
36
○ ●●● ○ ●●●●●●
Indicates Position / Draft sensitivity control knob fault
44
○ ●●●● ○ ●●●●
Indicates Position Sensor needs calibration
