1. Stay clear of raised boom
and bucket
2. Joystick button must always be
locked for safty when not using
implement.
Always set the knob to lock when
1. Traveling on the road
2. Replacing blades on an implement
3. Making adjustment to an implement
Sudden dropping of an implement
can cause serious injury or death
POSITION OF FUSE & RELAY
①
②
③
④
⑤
⑥
⑦
⑩
⑨
⑧
⑪
⑫
1. FUSE, HEATING TUBE 30A
2. FUSE, FUEL HEATER 50A
3. FUSE, CABIN 60A
4. FUSE MAIN 60A
5. RELAY, UREA HEATING TUBE1
6. RELAY, UREA HEATING TUBE2
7. FUSE BOX
8. RELAY, ECU
9. RELAY, FUEL HEATER
10. RELAY, STARTER
11. ECU
12. DCU
