1
GENERAL INFORMATION
Right turn
(Clockwise)
Left turn
(Counterclockwise)
Right Rear
Left
Front
J10O207A
5. REGARDING THE DIRECTION TERMS OF MACHINE
Terms such as front/back, left/right, left turn, right turn used in this manual is
shown in the gure.
