1. Introduction
With this unique device, you will have the basic devices needed for fault detection of electronic
boards: Oscilloscope, curve tracer, signal generator and short circuit finder.
UCE-DSO4200C can transmit all data to a PC via USB connection. This USB connection provides the
possibility to use the device with PC software.
In addition, this device can mirror the LCD screen image to a monitor via the HDMI output and can
be controlled with a wireless mouse.
In the curve tracer mode, passive elements can be checked without triggering active elements with
a 0.2V test signal. Thus, less component disassembly is ensured in troubleshooting.
In short-circuit finder mode, the short-circuit line on the PCB can be analyzed and its location can
be found.
Specifications:
• Display: 5.0-inch 800× 480 pixel color LCD with Touch screen
• Oscilloscope Channels: 2
• Curve Tracer Channels: 2
• Signal Generator Channel: 1
• PC connection: mini USB connector (USB 2.0 HID protocol).
• Storage: internal 4GB disk (microSD card)
• HDMI out for TV or Monitor (800×480 @60Hz)
• Multi-Device Wireless Mouse for Device and PC
• internal battery: 3.7V 10,000mAh (~4.5 hours)
• Power Consumption: 15W
• Dimensions: 170 x 200 x 140 mm
Features of Oscilloscope:
• Analog Bandwidth: 20MHz
• Maximum sampling rate: 8-bit 250 MS/s Real-Time Sampling, 6 GS/s Equivalent-Time Sampling
(ETS)
• Sampling depth: 8kB
• Input impedance: 1MΩ
• Vertical sensitivity: 5mV/div 10V/div
• Horizontal sensitivity: 10ns/div 500ms/div
